From the IBM
® Lotus
® Domino
® Administrator you can modify the current IMAP port configuration to:
- Enable or disable the IMAP TCP/IP or SSL port
- Change the TCP/IP or SSL port number
- Enable or disable TCP/IP or SSL authentication options
By default, IMAP clients connect to TCP/IP port 143 on the Domino
server. You might need to specify a different port number if there are
multiple instances of the IMAP service on the host machine as, for
example, on a partitioned server. You might also change the default port
to a nonstandard port number to "hide" it from clients attempting to
connect to the default port, or if another application uses the default
port on the server. Disable the port or change the security options to
prevent IMAP clients from accessing the Domino server.
Configuring IMAP authentication options on servers that use Internet Site documents
On servers that use Internet Site documents, the IMAP service obtains
port authentication settings from the Security tab of the IMAP Site
document, rather than from the Server document. As a result, when
Internet Site documents are used, the TCP/IP and SSL port authentication
settings described in the procedures that follow are not available in
the Server document. Settings in the Server document still provide the
port numbers and status for the IMAP TCP/IP and SSL ports, and enable
the IMAP ports to honor server access restrictions.
To determine whether the use of Internet Site documents is enabled
for a server, check the value of the following field on the Basics tab
of the Server document: "Load Internet configurations from
Server\Internet Sites documents." If this field is set to "Enabled," the
server uses Internet Site documents to configure all of its Internet
protocols (IMAP, POP3, SMTP, and so forth).
If the server uses Internet Site documents, and an IMAP Site document
is not present in the Domino Directory, or the authentication options
in a configured IMAP Site document are set to No, users cannot connect
to the IMAP service. In each case, IMAP clients receive the following
error when attempting to connect to the IMAP service:
This site is not enabled on the server.
To enable the IMAP TCP/IP port
- From the Domino Administrator, click the Configuration tab and then
open the Server document for the server that runs the IMAP service.
- Click the Ports - Internet Ports - Mail tab.
- To enable the default TCP/IP port, in the Mail (IMAP) column, change the value of the TCP/IP port status field to Enabled.
- Click Save and Close or edit additional settings, as directed in the following procedure.
Note On servers with multiple TCP/IP
ports, by default, the IMAP service uses the port listed first in the
NOTES.INI file as the preferred path. If you want the service to use a
port other than the default one, you can configure it to use a specific
port.
To configure the IMAP TCP/IP port
- From the Domino Administrator, click the Configuration tab and then
open the Server document for the server that runs the IMAP service.
- Click the Ports - Internet Ports - Mail tab.
- In the Mail (IMAP) column, complete these fields, and then click Save & Close:
Field
|
Enter
|
TCP/IP port number
|
Choose 143 (default) to use the industry standard port for IMAP
connections over TCP/IP. You can specify a different port, but 143 works
in most situations. When specifying a nonstandard port, make sure the
port is not reserved for another service. Port numbers can be any number
from 1 to 65535.
|
TCP/IP port status
|
Choose one:
- Enabled (default) - Allows IMAP clients to connect to the Domino
server without using SSL. Users must provide their name and Internet
password to connect.
- Disabled - Prevents IMAP clients from connecting to the Domino server, unless they can connect using SSL.
- Redirect to SSL - Denies access to clients connecting to the IMAP
TCP/IP port, but returns a message indicating that they must connect
over SSL. You can specify the contents of the message.
Note To support IMAP clients, either
the IMAP TCP/IP port or the IMAP SSL port must be enabled, and the IMAP
task must be running on the server.
|
Enforce server access settings
|
Choose one:
- Yes - Access to the IMAP service is controlled by the server access
settings on the Security tab of the Server document. Users who are not
allowed to access the server cannot access mail through the IMAP
service.
- No - (default) The IMAP service ignores the server access settings in the Server document.
|
- Restart the IMAP task to put the new settings into effect.
To enable and configure the IMAP SSL port
- Familiarize yourself with the IBM® Lotus® Domino® security model and set up SSL on the Domino server.
- From the Domino Administrator, click the Configuration tab and then
open the Server document for the server that runs the IMAP service.
- Click the Ports - Internet Ports - Mail tab.
- In the Mail (IMAP) column, complete these fields, and then click Save & Close:
Field
|
Enter
|
SSL port number
|
Choose 993 (default) to use the industry standard port for IMAP
connections over SSL. You can specify a different port, but 993 works in
most situations. When specifying a nonstandard port, make sure the port
is not reserved for another service. Port numbers can be any number
from 1 to 65535.
|
SSL port status
|
Choose one:
- Enabled - Allows IMAP clients to connect to the IMAP service over SSL.
- Disabled - (default) Prevents client connections over SSL.
|
Authentication options: Client certificate
|
If "SSL port status" is set to Enabled, choose one of the following:
- Yes - Allows IMAP clients to connect using client certificate authentication.
- No - (default) Prevents the IMAP service from using client certificate authentication.
|
Authentication options: Name & password
|
If the "SSL port status" field is set to Enabled, choose one of the following:
- Yes - Allows IMAP clients to use name-and-password authentication when connecting to the IMAP service over SSL.
- No - (default) Prevents IMAP clients from using name-and-password authentication over SSL.
|
- Restart the IMAP task to put the new settings into effect.
